Xenon X24
The Lumisphere® X24 Low Voltage System incorporates 24 volt Xenon Gas Filled Lamps of wattages of 5, 8.5 and 10w. These lamps have a life expectancy of approximately 20,000 hours at the appropriate circuit design voltage and are also extremely efficient with a colour temperature of 2700k. The X24 system is particularly suitable for permanent installation on buildings and structures where access for lamp changing is difficult. The lamps are multi position burning and resistant to vibration.
| Product Details | |
|---|---|
| Supply | Low Voltage, 24v AC. Dimmable on AC only. |
| Average Lamp Life | 20,000hrs Life Expectancy |
| Colour Temperature | 2700k – 3000k |
| IP Rating | IP68 Rated |
| Conformity | UL Listed |
| Warranty | Two Year Warranty |
| Product Options | |
|---|---|
| Light Sources | 5watt Xenon – Lumen output 40, 8.5watt Xenon – Lumen output 85, 10watt Xenon – Lumen output 90 |
| Globes | G type or A type (IK10 Rated) |
| Globe Colours | Clear, Frosted, White (G Type only), Red, Green, Blue, Purple, Amber and Pink |
| Lampholder/Cable Colour | Black or White |
Data Sheets available upon request
SELF-ASSEMBLY
Lumisphere’s Large and Small Harness festoon systems can be purchased in component form, if required, for self-assembly. In instances where irregular distances between light units are required, or on-site assembly of materials is required, e.g. signage, ceilings, fascias etc, this may preferable. On-site self-assembly tools can also be purchased – please ask the team for more details.
